Emuge - M10x1.00 MF 0 Flute 6H Modified Bottoming Fast Spiral Flute Tap
Item #: 18460444
Brand: Emuge
Model #: C3650F01.0276
Features and Benefits
Modified bottoming chamfers are similar to bottoming chamfers, but they are longer and have more teeth. They are used for threading blind holes and have 2 to 2-1/2 threads.
Powdered Metal (PM) is tougher and more cost effective than solid carbide. It is commonly used on highly abrasive materials including high silicon aluminums.
Fast Spiral Flutes with 40-53 degree angles are suitable for ductile materials like aluminum and copper; medium to high carbon steels and free machining stainless steels.
| Product Specifications | |
|---|---|
| Thread Size (mm) | M10x1.00 |
| Chamfer | Modified Bottoming |
| Class of Fit | 6H |
| Thread Limit | D5 |
| Number of Flutes | 0 |
| Material | Powdered Metal |
| Finish/Coating | TIN-60 |
| Thread Direction | Right Hand |
| Flute Direction | Right Hand |
| Through Coolant | Through Coolant |
| Overall Length (mm) | 90.00 |
| Thread Standard | MF |
| Oversize | No |
| Flute Type | Fast Spiral |
| Series/List | C3650F01 |
