Red Head - 7/8" Diam, 7/8" Drill, 1-1/4" Min Embedment Drop-In Concrete Anchor - Grade 3 Steel, Zinc-Plated Finish, Flat Head, Slotted Drive, 1" Thread Length
Item #: 06935795
Brand: Red Head
Model #: RL-58
Exact Tooling IR#: 04
Features and Benefits
Drop-in concrete anchors are internally threaded expansion anchors used with machine screws and bolts. They are ideal for use in concrete, block and stone.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Type | Drop-In |
| Diameter (Inch) | 7/8 |
| Drill Size (Inch) | 7/8 |
| Minimum Embedment (Inch) | 2-1/2 |
| Material | Steel |
| Material Grade | Grade 3 |
| Finish/Coating | Zinc-Plated |
| Head Type | Flat |
| Thread Size | 5/8-11 |
| Drive Type | Slotted |
| Thread Length (Inch) | 1 |
| Thread Length (mm) | 25.40 |
| Fastener Standard | ANSI B212.15; ASTM B633; ASTM E488 |
| For Use With | RT-158 |
| System of Measurement | Inch |
