Iscar - 12.5 to 17.4mm Groove Width, 93mm Max Depth of Cut, Right Hand Cut, CGH Indexable Grooving Blade - TIGER Insert Style, Series Cut Grip
Item #: 05413224
Brand: Iscar
Model #: 2898886
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Direction | Right Hand |
| Minimum Groove Width (mm) | 12.50 |
| Minimum Groove Width (Decimal Inch) | 0.4921 |
| Maximum Depth of Cut (mm) | 93.00 |
| Maximum Depth of Cut (Decimal Inch) | 3.6614 |
| Blade Style | CGH |
| Series | Cut Grip |
| Blade Height (mm) | 52.60 |
| Blade Height (Decimal Inch) | 2.0709 |
| Blade Width (mm) | 11.10 |
| Blade Width (Decimal Inch) | 0.4370 |
| Maximum Groove Width (mm) | 17.40 |
| Maximum Groove Width (Decimal Inch) | 0.6850 |
| Overall Length (mm) | 260.00 |
| Overall Length (Decimal Inch) | 10.2362 |
| Insert Style | TIGER |
| Complete Insert Compatibility | TIGER 1453-152; TIGER 1453-152-CW; TIGER 16.63-1.52; TIGER 1740-200 |
