Kennametal - MCLN, Right Hand Cut, 5° Lead Angle, 2" Shank Height x 2" Shank Width, Negative Rake Indexable Turning Toolholder - 8" OAL, CN..64. Insert Compatibility, Series Kenloc
Item #: 05195524
Brand: Kennametal
Model #: 1808153
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Right Hand |
| Toolholder Style | MCLN |
| Rake | Negative |
| Series | Kenloc |
| Lead Angle | 5 |
| Shank Width (Inch) | 2 |
| Shank Width (Decimal Inch) | 2.0000 |
| Shank Height (Inch) | 2 |
| Shank Height (mm) | 50.80 |
| Shank Height (Decimal Inch) | 2.0000 |
| Overall Length (Inch) | 8 |
| Overall Length (mm) | 203.20 |
| Overall Length (Decimal Inch) | 8.0000 |
| Insert Compatibility | CN..64. |
| Multi-Use Tool | No |
| Insert Holding Method | Screw or Clamp |
| Back of Bar to Cutting Edge (Decimal Inch) | 2.5000 |
| Head Length (Decimal Inch) | 1.4900 |
| Insert Inscribed Circle (Inch) | 3/4 |
| Insert Inscribed Circle (Decimal Inch) | 0.7500 |
| Toolholder Material | Steel |
