Turning Insert: EPGT4.51.8VL-W08 TH10, Solid Carbide Uncoated Finish, Left Hand, 0.0010″ Corner Radius, 75.0 ° N/A Diamond, Series EPGT
Item #: 02842862
Brand: Tungaloy
Model #: 6862182
Product Specifications
| Insert Style | EPGT |
| Insert Size Code | 4.51.8 |
| Insert Shape | Diamond |
| Insert Material | Solid Carbide |
| Manufacturer Grade | TH10 |
| Hole Diameter (Decimal Inch) | 0.0750 |
| Maximum Depth of Cut (Decimal Inch) | 0.0394 |
| Inscribed Circle (Decimal Inch) | 0.1410 |
| Insert Holding Method | Screw |
| Insert Hand | Left Hand |
| Insert Thickness (Decimal Inch) | 0.0550 |
| Corner Radius (Decimal Inch) | 0.0010 |
| Included Angle | 75.0 |
| Relief Angle | 11 |
| Series | EPGT |
| Coating Process | Uncoated |
| Rake | Positive |
| Wiper Edge | No |
| Number Of Cutting Edges | 2 |
| Primary Workpiece Material | Hard Material; Non-Ferrous Metal; Cast Iron; Super-alloys & Titanium |
| Primary Workpiece Material Code | S; H; K; N |
| Ansi Code | EPGT4.51.8VLW08TH10 |
| Iso Code | EPGT03X100L-W08 TH10 |
| Chip Breaker | W08 |
| Coating/Finish | Uncoated |
