Boston Gear - 8 Pitch, 1-1/4" Pitch Diam, 1.426" OD, 10 Tooth Helical Gear - 3/4" Face Width, 5/8" Bore Diam, 14.5° Pressure Angle, Steel - Benchmark Tooling

Boston Gear - 8 Pitch, 1-1/4" Pitch Diam, 1.426" OD, 10 Tooth Helical Gear - 3/4" Face Width, 5/8" Bore Diam, 14.5° Pressure Angle, Steel


Item #: 01218916
Brand: Boston Gear
Model #: 18096
Exact Tooling IR#: 04

Product Specifications
Type Helical Gear
Number of Teeth 10
Pitch Diameter (Decimal Inch) 1.2500
Bore Diameter (Inch) 5/8
Bore Diameter (Decimal Inch) 0.6250
Material Steel
Face Width (Inch) 3/4
Pressure Angle 14.5
PSC Code 3020
$89.16
