Value Collection - 1/2" Diam x 3-1/2" Pin Length Grade 8 Alloy Steel Pull Out Dowel Pin - 1 Rounded & 1 Threaded End
Item #: 00328799
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Standard pull out styles are designed for easy removal when frequent reassembly is required. They have a smooth finish and are used in applications featuring a through-hole.
Alloy steel is the strongest of all steel types. It has high tensile strength and offers excellent resistance to wear, fatigue and galling.
| Product Specifications | |
|---|---|
| Type | Standard Pull Out |
| Material | Alloy Steel |
| Pin Diameter (Inch) | 1/2 |
| Pin Length (Decimal Inch) | 3.5000 |
| Pin Length (Inch) | 3-1/2 |
| Fastener Standard | ASME B18.8.2 |
| Material Grade | Grade 8 |
| System of Measurement | Inch |
| Thread Size | 1/4-20 |
| End Type | (1) Rounded; (1) Threaded |
| Diameter Tolerance (Decimal Inch) | 0.0002 |
