SGS - 6mm, 8mm LOC, 6mm Shank Diam, 75mm OAL, 6 Flute, Solid Carbide Square End Mill - Single End, Ti-NAMITE-X Finish, Spiral Flute, 41° Helix, Centercutting, Right Hand Cut, Right Hand Flute, Series 51ML
Item #: 58978255
Brand: SGS
Model #: 45106
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Ti-NAMITE-X is a multi-layering process results in maximized tool life and increased speed and feed rates in any application. Ti-NAMITE-X is a proprietary coating exclusive to SGS Tool Company.
Center Cutting tools have one or more cutting edges at the tip and are used in a variety of applications including plunging, drilling or ramping.
| Product Specifications | |
|---|---|
| Mill Diameter (mm) | 6.00 |
| Mill Diameter (Decimal Inch) | 0.2362 |
| Number of Flutes | 6 |
| Length of Cut (mm) | 8.00 |
| Length of Cut (Decimal Inch) | 0.3150 |
| Material | Solid Carbide |
| Finish/Coating | Ti-NAMITE-X |
| Shank Diameter (mm) | 6.00 |
| Single or Double End | Single |
| Overall Length (mm) | 75.00 |
| Center Cutting | Center Cutting |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Helix Angle | 41.00 |
| Flute Type | Spiral |
| Length Type | Long Reach |
| Mill Diameter Tolerance (mm) | +0.000/-0.050 |
| Neck Length (Decimal Inch) | 0.9449 |
| Reach Length (mm) | 32.00 |
| Reach Length (Decimal Inch) | 1.2598 |
| Chipbreaker | No |
| Extended Reach | Yes |
| Shank Diameter Tolerance (mm) | +0.000/-0.008 |
| Series/List | 51ML |
