Sandvik Coromant - CNGN553 Grade 670 Ceramic Turning Insert - Uncoated, 80° Diamond, 5/8" Inscr Circle, 5/16" Thick, 3/64" Corner Radius
Item #: 49427719
Brand: Sandvik Coromant
Model #: 5724623
Exact Tooling IR#: 04
Features and Benefits
Ceramic is a highly heat resistant material composed of aluminum oxide and silicon nitride. It is commonly used at high speeds on steel, cast and ductile iron and high temperature alloys.
| Product Specifications | |
|---|---|
| Insert Style | CNGN |
| Insert Size | 553 |
| Material | Ceramic |
| Length (mm) | 16.12 |
| Length (Decimal Inch) | 0.6346 |
| Inscribed Circle (mm) | 15.88 |
| Inscribed Circle (Decimal Inch) | 0.6252 |
| Inscribed Circle (Inch) | 5/8 |
| Thickness (Inch) | 5/16 |
| Thickness (Decimal Inch) | 0.3126 |
| Thickness (mm) | 7.94 |
| Corner Radius (Inch) | 3/64 |
| Corner Radius (mm) | 1.20 |
| Corner Radius (Decimal Inch) | 0.0472 |
| Manufacturer's Grade | 670 |
| Coating | Uncoated |
| ISO Number | CNGN160712T01020670 |
| Relief Angle | 0 |
| Manufacturers Catalog Number | 5724623 |
| Primary Workpiece Material | H; S |
| Included Angle | 80 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | T-Max |
| Maximum Depth of Cut (mm) | 14.92 |
| Maximum Depth of Cut (Decimal Inch) | 0.5874 |
| Insert Holding Method | Clamp |
| Cutting Edge Style | Negative Land |
| Shape | Diamond |
