Supermill - Square End Mills; Mill Diameter (Inch): 3/4 ; Mill Diameter (Decimal Inch): 0.7500 ; Number of Flutes: 6 ; Length of Cut (Inch): 4 ; Length of Cut (Decimal Inch): 4.0000 ; Material: Solid Carbide
Item #: 18155002
Brand: Supermill
Model #: SM6F750XXLA
Product Specifications
Square End Mills; Mill Diameter (Inch): 3/4 ; Mill Diameter (Decimal Inch): 0.7500 ; Number of Flutes: 6 ; Length of Cut (Inch): 4 ; Length of Cut (Decimal Inch): 4.0000 ; Material: Solid Carbide
| Mill Diameter (Inch) | 3/4 |
| Mill Diameter (Decimal Inch) | 0.7500 |
| Number of Flutes | 6 |
| Length of Cut (Inch) | 4 |
| Length of Cut (Decimal Inch) | 4.0000 |
| Material | Solid Carbide |
| Finish/Coating | AlCrN |
| Shank Diameter (Inch) | 3/4 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Overall Length (Inch) | 7 |
| Overall Length (Decimal Inch) | 7.00000 |
| Helix Angle | 45 |
| Variable Helix | No |
| Variable Index | Yes |
| Material Grade | Micrograin |
| Chipbreaker | No |
| Series/List | SM6F-NB |
