Everede Tool - WCGT002 Grade CV6 Carbide Boring Insert - TiN Finish, 80° Trigon, 7° Relief Angle, 5/32" Inscr Circle, 1/16" Thick, 0.002" Corner Radius
Item #: 01607795
Brand: Everede Tool
Model #: WCGT-002-CV6
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, steel, plastic and other tough-to-machine materials. Application is determined by material grade.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | WCGT |
| Insert Size | 002 |
| Material Grade | C5/C6 |
| Manufacturer's Grade | CV6 |
| Inscribed Circle (Inch) | 5/32 |
| Inscribed Circle (Decimal Inch) | 0.1560 |
| Thickness (Decimal Inch) | 0.0620 |
| Thickness (Inch) | 1/16 |
| Corner Radius (Decimal Inch) | 0.0020 |
| Coating | TiN |
| Hole Diameter (mm) | 2.00 |
| Relief Angle | 7 |
| Included Angle | 80 |
| Coating Process | CVD |
| Insert Holding Method | Screw |
| Shape | Trigon |
